W+D 241 GSV .38

Year: 1987

Reference: 241-ERB0025

MACHINE DESCRIPTION

Production of large format Booklets and Centre Seam Pockets

Reel fed

Non window

4 dr blade printing

SPECIFICATION INFO

Stork reel splicer

Magnetic cylinder side knifes

Tools for Ø154, Ø148

Blank feed unit

Print 1+3 or 2+2 doctor blades

Window unit

Magnetic window cut (K+B)

W+D window splicer

Side glue system original

W+D Silicone P+S unit - cold glue application

Dextrin seal flap gumming device

Latex seal flap gumming device

Outside side seams

New main motor, servo

TECHNICAL DATA

Size range envelopes:

Wallet min. 110 x 120 mm, max. 305 x 420 mm


Size range pockets:

Centre seam min. 228 x 152 mm, max. 381 x 254 mm


Speed:

max. output: up to 500 pockets per minute [W+D catalogue]


Paper weights:

70 - 165 g/m²
